New Ce Certificated Telescopic Cylinder Boom Loader (HQ915T) for Sale

Specifications:

1. CE certificate and Euro III engine
2. Europe Quick hitch
3.Fully Hydraulic Driving , Hydraulic converter System
4, Multi function with Joystick operation.

Telescopic wheel loader:

1.0 Engine Details
(1) Model: Chinese Euro III Xinchai A498BPT
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW (50.32H. P. )
(4) Rated Speed: 2200 r/p. Min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g/kw. H

2.0 Transmission System
Hydraulic converter + drive shaft + axles

3.0 Bucket4.0 Overall Dimensions
(1) Overall Length: 4320mm
(2) Overall Height: 2670mm
(3) Overall Width: 1720mm
(4) Max. Lifting Height: 4250mm

5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4950mm
(3) Driving System: Hydraulic converter, four wheel drive
(4) Quick coupling system
(5) Joystick
(6) Self levering

6.0 Brake System
(1) Service Brake: Four Wheel Chuck brake
(2) Parking Brake: Hand operated

7.0 Tyre
(1) Model: 12-16.5 / 14-17.5/ 16-70/20

8.0 Wheelbase: 2400mm

9.0 Track: 1345mm

10. System pressure: 20Mpa; Hydraulic output: 70L/min
