    Weifang Wheel Loader 920
    • Weifang Wheel Loader 920Weifang Wheel Loader 920
    • Weifang Wheel Loader 920Weifang Wheel Loader 920
    • Weifang Wheel Loader 920Weifang Wheel Loader 920
    • Weifang Wheel Loader 920Weifang Wheel Loader 920

    Weifang Wheel Loader 920

    Description of 920 wheel loader Engine Details Model:Xichai 4102/ Xinchai 498BT(EURO III)Engine type:In-line arrangement, water-cooled, four-cycle diesel EngineRated Power:37-45kwRated Speed:2200 r/min (rpm)Fuel Consumption ratio in standard working condition:243g/kw.h Transmission SystemTorque Co......

    Send Inquiry

    Product Description

    Description of 920 wheel loader


    Engine Details

    Model:Xichai 4102/ Xinchai 498BT(EURO III)
    Engine type:In-line arrangement, water-cooled, four-cycle diesel Engine
    Rated Power:37-45kw
    Rated Speed:2200 r/min (rpm)
    Fuel Consumption ratio in standard working condition:243g/kw.h


    Transmission System
    Torque Converter ModelYJ265
    Gear Box ModelYJB152 YJB152A
    Type:Fixed-spindle Power shift
    Shift gear control oil pressure:1.2-1.5MPa
    Rated input speed:2500 (rpm)
    SpeedGear Shift2 Forward Shift, 2 Reverse Shift
    Max Speed24km/h

    Bucket

    Bucket Capacity:0.8m3
    Bucket width:1620mm
    Bucket type:Heavy-duty bolt on teeth
    Max. Breakout Force:≥45
    Rated Load:1600kg
    Operating Weight:4500kg
    Overall Dimensions

    (1) Overall Length (Bucket on ground position):5600mm

    Overall Height

    (a) Ground to Cab Top:2700mm
    (b) Ground to exhaust pipe:It is below from the top of cabin
    (c) Dumping Height:2800/3100/4300 mm
    Overall Width:2000mm
    Operating Specifications

    Steering System:Articulated Frame with hydraulic power steering
    Min Turning Radius:4800mm
    Driving System:Hydraulic converter
    Operation Weight4500kg

    Weifang Wheel Loader 920
    Weifang Wheel Loader 920
    Weifang Wheel Loader 920

    Advantage
    Rops approved:the cabin space is 30% larger than normal.
    2.xinchai engine :powerful ,low emission ,low fuel consumption,low noise ,moneysaving.
    3.Eougem wheel reductor,Oscillating rear alxe for best stability.
    4.Extremely strong articulation joint
    5.very strong carriage fast and safe hydraulic coupling of tools .
    6.versatile due to big range of tools and optional equipment.
    7.cabin can roll, so it is convenient to repair

    Why choose us?
    1). The quality is guaranteed due to strong technical support ,high quality component ,advanced production line and strict quality control system.
    2). One-stop service with a large spare parts warehouse and professional service team .No matter where you are, you are guaranteed of eougem warm reception, trustworthy and efficient professional services and persistent care.
    3). we have testing center every machine must test 5 hours before delivered.
    4). we have been in the line business for more than ten years.

    Pre-Sales Service
      1.Inquiry and consulting support in 24 hours.
      2.View our factory.Drive and test the machine by customers.
      3.Use trade assurance to ensure customer safety.
    After-Sales Service
      1.Training how to instal the machine, training how to use the machine.?
      2.Engineers available to service machinery overseas.
