Product Description
Features:
1. The electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts universality, and low maintenance cost.
2. The machine is provided with three working power modes at your choice depending on the specific load need under actual working condition to realize the reasonable match among power, efficiency, and power consumption. The unique one-touch boost mode can be used for escape from mud entrapment.
| Parameter name | DH17-C2 XL (Extended version) | DH17-C2 LGP(Super-wetland version) | DH17-C2 WH (Environmental sanitation version) | DH17-C2 DS (Desert version) | DH17-C2 RS (Rock version) | DH17-C2 FL (Forestry version) | DH17-C2 CH (Coal version) |
| Performance parameters | |||||||
| Operating weight (Kg) | 18340 (With traction frame)/19241 (With ripper) | 20200 | 20140 | 20600 | 19176 | 19985 (With traction frame)/21725 (With winch) | 18700 |
| Ground pressure (kPa) | 67.2 | 31.2 | 31.1 | 43.3 | 58.75 | 55.5 (With traction frame)/60.7 (With winch) | 57.3 |
| Engine | |||||||
| Engine model | WP10 | WP10 | WP10 | WP10 | WP10 | WP10 | WP10 |
| Rated power/rated speed (kW/rpm) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) | 162/1900 (Heavy-duty mode) 141/1820 (Standard mode) 120/1750 (Light-duty mode) |
| Overall dimensions | |||||||
| Overall dimensions of machine (mm) | 5250*3420*3080 | 5340*4150*3091 | 5586*4150*3091 | 5340*4150*3091 | 5250*3420*3080 | 6320*3438*3210 | 5250*3420*3080 |
| Driving performance | |||||||
| Forward speed (km/h) | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 |
| Reversing speed (km/h) | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 | 0~10 |
| Chassis System | |||||||
| Center distance of track (mm) | 1880 | 2350 | 2350 | 2350 | 1880 | 1880 | 1880 |
| Width of track shoes (mm) | 510/560/610 | 1100/950 (Swamp type)/900 (Single grouser) | 1100/950 (Swamp type) | 810 (Single grouser)/1100/950 (Swamp type) | 610 | 610 | 610/510/560 |
| Ground length(mm) | 2675 | 2935 | 2935 | 2935 | 2675 | 2935 | 2675 |
| Tank capacity | |||||||
| Fuel tank (L) | 305 | 305 | 305 | 305 | 305 | 305 | 305 |
| Working device | |||||||
| Blade type | Semi-U blade/straight tilting blade | Straight tilting blade | Sanitation blade | Straight tilting blade | Rock blade | Angle Blade | Coal blade |
| Digging depth (mm) | 520 | 485 | 485 | 485 | 520 | 485 | 520 |
| Ripper type | Three-shank | -- | -- | -- | -- | -- | -- |
| Ripping depth (mm) | 475 | -- | -- | -- | -- | -- | -- |
