Applicable materrialsStainless Steel, Carbon Steel, Copper, Alloy Steel, Galvanlzedplate, Aluminum Plate, Titaniumalloy and other alloy plate.Technical Parameters ModelUnitLM3015HLM4020HLM6020HWork areamm3000*15004000*20006000x2000Position accuracymm ±0.02/1000 Reposition accuracymm &......
Model | Unit | LM3015H | LM4020H | LM6020H | |||
Work area | mm | 3000*1500 | 4000*2000 | 6000x2000 | |||
Position accuracy | mm | ±0.02/1000 | |||||
Reposition accuracy | mm | ±0.03 | |||||
Maximum speed | m/min | 140 | |||||
Maximum accelerated speed | G | 1.5 | |||||
Laser model | Fiber laser generator | ||||||
Laser power | W | 800-3000 | |||||
Max. cutting speed | Depending on the material and thickness | ||||||
Transmission system | Gantry double-drive structure | ||||||
Operating platform | Full automatic double exchange operation platform | ||||||
Power supply | Triphase 380V/50Hz/60Hz | ||||||
Total power | <8KW (not include the laser) | ||||||
Overall dimension | mm | 8000*3500 (lb working area 3000x1500 for example) | |||||
