China High Rigidity 3-Axis Vertical Machining Center Vmc 1160

Product Description

Specification

TRAVEL
X/Y/Z axis travel	1100x600x600mm
Spindle nose to table	100-700mm
Spindle center to column	690mm
Positioning accuracy	±0.003/300mm
Repeated positioning	±0.002/300mm
Spindle
Spindle taper	BT40
Spindle transmission	Direct drive
Spindle speed	12000 rpm/min
Controller
CNC control	Fanuc 0i-MF
Spindle motor	11/15 kw 12000 rpm/min
X/Y/Z motor	3.0/3.0/3.0kw
Table
Table size ( W x L )	1200x600mm
T slot	5-18x100mm
Table load	800kg
Feed
X/Y/Z rapid feed rate	36/36/36m/min
X/Y/Z linear guideway	Roller type 45/45/45
X/Y/Z ball screw	12mm-ball
MACHINE DIMENSION
Dimension	320029002600mm
Weight	7500kg

Main parts list:

Item	Brand
Spindle	Taiwan-Spintrue
Spindle bearing	Japan-NSK
Ball screw	Taiwan-PMI-C3
Linear guideway	Taiwan-PMI
Pneumatic parts	Taiwan-Mindman
Electric parts	Japan-Mitsubishi/Omron
Tool magazine	Taiwan- 24T Arm type

Optional configuration:
- SIEMENS/FANUC/Mitsubishi CNC Controller
- 4th/5th axes rotary table
- Chip conveyor
- Tool setter
- Oil mist collector
